8.8mm Antistatic Edge Corrugated Machine Spare Parts Double Facer Belts

Product Categories
Liyuan Technology (Guangzhou) Co., LTD
Contact Now

8.8mm Antistatic Edge Corrugated Machine Spare Parts Double Facer Belts

Brand Name : Lycorrugated

Model Number : EDGE REINFORCEMEN FCH-FZ

Certification : CE, ISO, TUV, SGS

Place of Origin : Guangdong,China

MOQ : 1 Set

Price : Factory Price

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 80000 meters per year

Delivery Time : 30-35 work days

Packaging Details : Case

NEIGHT KG/M2 : 7.3

THICKNESS mm : 8.8±0.3

WIDTH mm : 1400-3300

THERMAL ENDURANCE℃ : 1400-3300 mm

Thermal Endurance : 180℃

FRICTION FACTOR : 0.45

Contact Now

Corrugated Machine Spare Parts 8.8mm Antistatic Edge Reinforcemen Double Facer Belt

Performance Index:

MODEL

EDGE REINFORCEMEN

FCH-FZ
NEIGHT KG/M2 7.3
THICKNESS mm 8.8±0.3
WIDTH mm 1400-3300
THERMAL ENDURANCE℃ 180℃
FRICTION FACTOR 0.45
BREAKING STRENGTH KG/M 30000
MOISTURE ABSORPTION /RELEASE RATIO 129%
STEAM LM2-H 6.560
FLEXIBILITY TRANSVERSE 0.77%/180℃
FLEXIBILITY LONGITUDINAL 0.9%/180℃

Weaving technic: multi-layer single filing

Material: polyester yarn, polyester filament, Tencel and Kevlar

Feature: weaving texture clear, neat edge, stable dimension, heat and pressure-resisting , anti-static, outstanding traction, surface and seam-sealing even.

Great absorbency, drying and anti- static enable corrugated board transport flawlessly and efficiently in production line

Lifetime: 80 million meter service length in laboratory test condition

Feature:

1, The first domestic machine capable of producing a conveyor belt with a large width of 3300 mm

2, Obtained a patent for the anti-collision edge

3, The unique Company participating in the domestic industry standard customization of conveyor belts
4, The surface of the conveyor belt is made of Austrian imported Tencel, which improves water absorption and air permeability by 7.8%
